| Name: | Allison Transmission Straight Through Seal and Gasket Kit 29550017 |
|---|---|
| DESC.: | 4TH GEN SEAL & GASKET W/OE C3/C4 PISTONS,MD + UNIVERSAL 4TH GEN VB KIT (29550017 + PARTS FOR BOTH 4TH GEN VB KITS) |
| OEM NO.: | 29550017 |
| APPLICATION: | Allison Transmissions Gearbox |
Product Description
4TH GEN. OVERHAUL KIT and VB KIT FOR ALLISON MD/B400/3000/T200 TRANSMISSION 29550017
The Straight Through Seal and Gasket Kit contain all the seals, o-rings, and gaskets needed to seal the transmission.
Covers:
23045613 C2 external seal ring, 234.1 mm OD (1)
23046274 turbine shaft o-ring, 25.1 mm ID (1)
23047185 oil pump o-ring, 110.7 mm ID (1)
23048037 PTO cover gasket (2)
23049377 converter pump-to-cover o-ring, 368.3 mm ID (1)
29501567 external spiral retaining ring, 43.5 mm ID (1)
29502439 flange button output o-ring, 66.3 mm ID (1)
29503208 o-ring, 34.6 mm ID (1)
29503288 converter housing gasket (1)
29503383 speed sensor o-ring, 15.4 mm ID (2)
29503547 cooler port cover gasket (1)
29510682 C5 internal seal ring, 140.3 mm OD (1)
29512875 retaining plate bolt o-ring, 12.3 mm ID (1)
29521240 external seal ring, 88 mm OD (5)
29524120 external seal ring (3)
29524121 external seal ring (2)
29532361 instructional sheet No. 278 (1)
29534354 rear cover gasket (1)
29535219 hex bolt, M14 x 2 x 70 (1)
29539807 external spiral retaining ring, 46.2 mm ID (1)
29540988 washer (1)
29544137 oil input seal assembly (1)
29545518 oil seal assembly (1)
29546153 C2 seal ring, 116.3 mm ID (1)
29546154 C1 seal ring, 101.1 mm ID (1)
29546155 C1 and rear bearing seal ring, 178.8 mm ID (2)
29546156 balance piston seal ring, 202.1 mm ID (1)
29546157 C5 external seal ring, 258.7 mm ID (1)
29546165 lockup piston seal ring, 279.9 mm ID (1)
29546166 lockup piston seal ring, 86.9 mm ID (1)
29546229 fill tube seal (2)
29556870 oil seal assembly (1)
29559230 turbine hub polymer seal ring, 61.4 mm OD (1)
29561880 C3/C4 piston (2)
WHY IT MATTERS
The kit is key to creating proper seals when assembling the transmission to prevent leaks and unnecessary component damage.
BENEFITS
All-inclusive kit
Forms a tight seal around a component
Prevents leaks
Built to original factory specifications
SIGNS OF NEEDING REPLACEMENT
Leaks
CAUSES OF FAILURE
Worn components
Incorrect replacement of parts
